Daylight iQ ESD Daylight & UV Magnifier Lamp (U25101)

*This item is drop-shipped from the manufacturer. Not eligible for Expedited/Rush shipping or In-Store Pick-Up. Inventory for drop-shipped items is not guaranteed.

The iQ ESD™ is a 100% ESD-safe illuminated magnifier, independently certified for use in EPA (Electrostatic Protected Areas) to IEC 61340-5-1 & ANSI/ESD 20:20. A fantastic 2-in-1 light source, powerful Daylight 6,000K LEDs ensure clarity and shadow-free illumination while UV-A (365nm) LEDs are ideal for conformal coating inspection, as well as thorough checking of soldered joints, welds, and any other mechanical stress areas. With 2 brightness levels to suit your tasks, joints that hold any position and a large 17.5cm lens, the iQ ESD™ is the ultimate 2-in-1 ESD-safe illuminated magnifier.

Technical Details:

• Light source: LED
• Lumens: 700lm
• Lux output at 6″: 6,000 and 4,000
• Light color temperature: 6,000K
• CRI: 95+
• UV light source: LED UV-A
• UV wavelength: 365nm
• Energy consumption: 12W
• Product color: Black
• Maximum reach: 47″
• Product weight: 8.3lb
• Cable length: 78.7″

Key Features:

• 2-in-1 light source: powerful Daylight 6,000K LEDs and UV-A (365nm) LEDs
• 100% ESD-safe illuminated magnifier that is independently certified
• Optical quality glass lens 7″
• 3 diopters magnification (1.75X) supplied with additional 12 diopters (4X) swing arm magnifier
• Exceptionally strong and durable carbon fiber head and joints
• No adjustment necessary: specifically constructed using free motion joints instead of wing nuts, the iQ ESD will always hold its position
• 2 brightness levels to adapt the lighting to your task at hand
• Long reach of 47″ so you position light exactly where you need it
• 5-year guarantee

Recommended For:

• Industry & Inspections:
• ESD safe environments
• Professional applications
• Electronic components
• Soldering
• Checking conformal coatings on PCBs
